Accsoon CineView Master 4K TX/RX Wireless Video Transmission System

Groundbreaking Wireless 4K 60P Video. Tri-Band Stability. Pro-Level Monitoring.

The Accsoon CineView Master 4K TX/RX system redefines on-set video monitoring, delivering true 4K 60P wireless transmission with ultra-low latency and Tri-Band Wi-Fi technology (6GHz, 5GHz, 2.4GHz). Designed for professional filmmakers, content creators, and live production teams, it’s the world’s first system to combine high-speed 4K 60P Wi-Fi video, less than 25ms latency, and MFi-certified iOS monitoring via cable.

Powered by Accsoon’s next-gen 8K-capable A/V processor and proprietary RTMS 4.0 transmission protocol, the CineView Master 4K is built for speed, stability, and adaptability—delivering market-leading performance in any production environment.

Key Innovations:

• True 4K 60P Wireless Video over Wi-Fi with <25ms latency (1080p); ~35ms (4K)

• Tri-Band Wi-Fi (6GHz/5GHz/2.4GHz) with DFS support for extended range and minimal interference

• 2.5 km / 1.5 mile transmission range (line-of-sight)

• Simultaneous Output to 4 Devices wirelessly + 1 wired iOS monitor

• HDMI + SDI Input/Output on both TX and RX for full broadcast workflow compatibility

• Powerful 8K-ready Processor with 400% processing power increase for real-time video handling

• MFi-Certified Cable Monitoring for iPad/iPhone with up to 32Mbps bandwidth

• SEE App Integration for LUTs, focus peaking, waveform, vertical shooting & Frame.io C2C uploads

• Individually Configurable Output Resolutions (4K or HD per RX/iOS device)

• Quiet, Intelligent Cooling System with Standard, Quiet, and Off modes

Ideal For:

• Film & TV Production

• Live Events & Broadcast

• Commercial Shoots

• Multi-cam Studios

• Remote Collaboration & Camera-to-Cloud workflows

What's Included:

• 1x CineView Master 4K TX Transmitter

• 1x CineView Master 4K RX Receiver

• 1x Cold Shoe Mount

• 4x Antennas (Tri-Band)

• 1x USB-C to USB-C Cable

• 1x USB-C to Lightning Cable

• 1x Allen Key

• 1x User Manual

Technical Specs – TX & RX Overview

Video Input (TX): HDMI 2.0, 3G-SDI
Video Output (RX): HDMI 2.0, 3G-SDI
Loop-Out (TX): HDMI 2.0
Latency: <25ms (1080p), ~35ms (4K)
Range: ≥2.5 km LOS
Processor: 8K High-Performance A/V Processor
Transmission Protocol: Accsoon RTMS 4.0
Power: NP-F battery or 7.4–16.8V DC input
Dimensions (TX/RX): 130 x 95 x 32mm
Weight (TX): 322g | RX: 320g
Operating Temp: -10°C to 40°C
Audio: HDMI/SDI embedded

Experience next-generation wireless video with zero compromise.
The Accsoon CineView Master 4K TX/RX delivers the flexibility, speed, and quality that today’s productions demand.
