Atomos Shinobi 7 Photo and Video Monitor

The Atomos Shinobi 7 is a professional-grade 7-inch 4K HDR monitor designed for photographers, videographers, vloggers, and filmmakers. With a bright, daylight-viewable display, advanced monitoring features, and flexible connectivity, it’s an essential tool for accurate image evaluation and creative control on set or in the field.

Key Features

Exceptional Display

• 7-Inch 4K HDR Touchscreen: Provides crystal-clear viewing with vibrant colours and high contrast.
• 2200 Nits Brightness: Daylight-viewable screen for outdoor use without compromise.
• HDR Monitoring: Displays over 10 stops of dynamic range from Log, PQ, and HLG signals.

Advanced Monitoring Tools

• 3D LUT Support: Load up to 8 custom LUTs via the SD card slot for real-time preview and consistent creative intent.
• Comprehensive Exposure Tools: Includes histogram, waveform, false colour, and zebras for precise exposure monitoring.
• Focus Peaking and Zoom: Pull focus confidently with 4:1, 2:1, and 1:1 zoom options.
• Atomos Analysis Mode: View waveform, histogram, and vectorscope simultaneously for full image control.
• Frame Guides: Supports cine and social media formats, including SMPTE Safe Area.

Flexible Connectivity

• HDMI 2.0 and SDI Inputs/Outputs: Handles up to 4Kp60 via HDMI and 2Kp60 via SDI.
• Bi-Directional HDMI <> SDI Cross Conversion: Simplifies integration into mixed workflows.
• 4K to HD Down Conversion: Optimises compatibility with various display systems.

Camera Control Functionality

• Touchscreen Camera Controls: Compatible with Z Cam E2 series cameras for direct adjustments to iris, white balance, shutter angle, and ND with an optional USB-C to serial cable.

Durable and Portable Design

• Lightweight Yet Robust: Optimised for portability and professional use.
• Dual NPF Battery Slots: Hot-swap batteries for uninterrupted power throughout the day.
• DC Power Input: Dedicated locking jack and optional DC to D-Tap cable for external power.

User Calibration

• Factory and User Calibration: Pre-calibrated for Rec.709 and supports user calibration with X-Rite i1DisplayPro/Plus and Atomos Calibration software.

Specifications

• Display Size: 7 inches
• Brightness: 2200 nits
• Input/Output: HDMI 2.0 (4Kp60), 3G-SDI (2Kp60)
• Battery Slots: Dual NPF
• Weight: Lightweight for handheld or mounted use

Ideal Applications

• On-Set Monitoring: Perfect for directors, focus pullers, and camera operators.
• Vlogging and Self-Shooting: Features vertical and horizontal screen modes for selfie or piece-to-camera setups.
• HDR Production: Ideal for filmmakers requiring real-time Log to HDR monitoring.

Order the Atomos Shinobi 7 Today
Take control of your creative workflow with the Atomos Shinobi 7 Photo and Video Monitor. Combining advanced monitoring tools, flexible connectivity, and a brilliant 7-inch display, it’s the ultimate solution for professional monitoring in any environment. Elevate your visuals and make every shot count!
