DJI Focus Pro LiDAR

Sharper Focus. Smarter Precision for Professional Filmmaking

The DJI Focus Pro LiDAR is an advanced focusing system designed for filmmakers who require exceptional autofocus accuracy, improved subject detection, and reliable performance in challenging shooting environments. With an impressive 76,800 ranging points, this next-generation LiDAR module dramatically improves depth detection, reduces focus hunting, and delivers fast, dependable autofocus—even in low-contrast scenes or fast-moving situations.

When paired with the DJI Focus Pro Motor, the LiDAR system enables autofocus for manual lenses, giving creators the freedom to use cinema glass while still benefiting from intelligent focusing technology.

---

Advanced LiDAR Depth Mapping

The DJI Focus Pro LiDAR uses 76,800 ranging points, representing a significant increase in depth data compared to earlier systems.

Benefits include:

• Improved edge detection

• Reduced focus hunting

• Greater focus reliability

• More accurate subject tracking

This allows operators to maintain sharp focus even when filming complex scenes or dynamic subjects.

---

Extended Focus Range for Telephoto Lenses

The system supports accurate focusing at distances of up to 20 metres, making it suitable for long-lens filming and distant subjects.

Two zoom modes are available:

• 1× Mode – up to 10m focusing range

• 2× Zoom Mode – extends focusing distance up to 20m

This flexibility allows filmmakers to adapt the system for different shooting scenarios.

---

Wide Field of View for Flexible Framing

The LiDAR module provides a wide scanning area, giving operators more freedom when composing shots.

Field of view:

• Wide Mode:

  • 65° horizontal

  • 40° vertical

  • 76.1° diagonal

• Tele Mode:

  • 20° horizontal

  • 20° vertical

  • 28.3° diagonal

This wider sensing area improves tracking accuracy when subjects move across the frame.

---

Fast Real-Time Subject Tracking

The 30Hz refresh rate allows the LiDAR system to continuously analyse depth information and track subjects in real time.

This enables:

• Smooth autofocus transitions

• Accurate tracking of moving subjects

• Reliable focus performance during action scenes

---

Autofocus for Manual Lenses

When used with the DJI Focus Pro Motor, the LiDAR system enables automatic focusing with manual lenses.

This feature allows filmmakers to combine:

• Cinematic manual lenses

• Modern autofocus capabilities

It is especially useful for cinema productions, documentaries, and handheld filming setups.

---

Compact and Lightweight Design

Despite its powerful capabilities, the Focus Pro LiDAR remains compact and lightweight, making it easy to integrate into professional camera rigs.

• Weight: 140g

• Dimensions: 68 × 25 × 57 mm

This ensures seamless integration with gimbals and stabilised camera systems without significantly increasing rig weight.

---

Key Features

• 76,800 LiDAR ranging points

• Accurate focusing up to 20m

• 70° wide field of view

• 30Hz refresh rate for real-time tracking

• Two zoom modes for extended focusing

• Autofocus capability for manual lenses

• Compact and lightweight design

• Enhanced edge detection and reduced focus hunting

---

Technical Specifications

Specification	Details
Ranging Points	76,800
Sensing Range	0.5 – 20 m
Field of View (Wide)	65° H / 40° V / 76.1° D
Field of View (Tele)	20° H / 20° V / 28.3° D
Frame Rate	30 fps
Equivalent Focal Length	30 mm (wide-angle mode)
Ranging Accuracy	±1% – 3% (distance dependent)
Power Consumption	Avg. 6.3 W / Max 6.8 W
Input Voltage	6.6 – 17.2 V
Operating Temperature	–20°C to 45°C
Dimensions	68 × 25 × 57 mm
Weight	140 g

---

Compatibility

The DJI Focus Pro LiDAR is compatible with:

• DJI RS 4 Pro

• DJI RS 3 Pro

• DJI Focus Pro Grip

---

What’s in the Box

• DJI Focus Pro LiDAR ×1

• Multi-Camera Control Cable (USB-C, 30 cm) ×1

---

Precision Focus for Professional Productions

The DJI Focus Pro LiDAR brings cutting-edge depth sensing technology to modern filmmaking, enabling fast, accurate autofocus and reliable subject tracking even when using manual lenses. With its powerful LiDAR mapping, extended focus range, and compact design, it provides filmmakers with greater creative control and confidence when capturing critical shots.
